Silicon carbide crucible TPX843 Tp587 Tp412 Tp800 Tp487

Short Description:

Our Silicon carbide crucibles are high-performance refractory containers made of high-purity silicon carbide material, designed for high temperature applications. Thanks to their excellent heat resistance, corrosion resistance and mechanical strength, our silicon carbide crucibles excel in die casting, aluminum casting, recycled aluminum and electromagnetic induction furnaces, especially in terms of performance, providing customers with more efficient and durable solutions.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Crucible Quality

Withstands Myriad Smelts

PRODUCT FEATURES

Superior Thermal Conductivity

The unique blend of silicon carbide and graphite ensures rapid and uniform heating, significantly cutting down on melting time.

Extreme Temperature Resistance

The unique blend of silicon carbide and graphite ensures rapid and uniform heating, significantly cutting down on melting time.

Durable Corrosion Resistance

The unique blend of silicon carbide and graphite ensures rapid and uniform heating, significantly cutting down on melting time.

TECHNICAL SPECIFICATIONS

Graphite / %	41.49
SiC / %	45.16
B/C / %	4.85
Al₂O₃ / %	8.50
Bulk density / g·cm⁻³	2.20
Apparent porosity / %	10.8
Crushing strength/ MPa (25℃)	28.4
Modulus of rupture/ MPa (25℃)	9.5
Fire resistance temperature/ ℃	>1680
Thermal shock resistance / Times	100

No.	H (mm)	D (mm)	d (mm)	L (mm)
TP 173 G	490	325	240	95
TP 400 G	615	360	260	130
TP 400	665	360	260	130
TP 843	675	420	255	155
TP 982	800	435	295	135
TP 89	740	545	325	135
TP 12	940	440	295	150
TP 16	970	540	360	160

Click Tere To Get More

PROCESS FLOW

1. Precision Formulation

High-purity graphite + premium silicon carbide + proprietary binding agent.

2.Isostatic Pressing

Density up to 2.2g/cm³ | Wall thickness tolerance ±0.3m

3.High-Temperature Sintering

SiC particle recrystallization forming 3D network structure

4. Surface Enhancement

Anti-oxidation coating → 3× improved corrosion resistance

5. Rigorous Quality Inspection

Unique tracking code for full lifecycle traceability

6. Safety Packaging

Shock-absorbent layer + Moisture barrier + Reinforced casing

PRODUCT APPLICATION

Gas Melting Furnace

Induction Melting Furnace

Resistance Melting Furnace

WHY CHOOSE US

Product advantage: Compared with other sic crucibles

1 For die casting industry

We use advanced graphite silicon carbide material, specially developed for the die casting industry, more suitable for low temperature environment. Excellent oxidation resistance in low temperature environment, extending the service life by 20%. The thermal conductivity is 17% faster than the traditional silicon carbide graphite crucible, and the energy saving effect is significant and more environmentally friendly. More stable performance in die casting environments, reduced replacement frequency and lower customer costs.

2 For aluminum casting industry

Optimized on the basis of traditional European sic crucible formulations to further improve the antioxidant performance. We can ensure that the sic crucible itself does not gas out, protect the purity of the liquid aluminum, and provide customers with higher quality casting products. Excellent corrosion resistance in aluminum casting environments and extended service life.

3 For the recycled aluminum industry

Our silicon carbide crucibles is particularly outstanding in the recycled aluminum industry, and its corrosion resistance is far better than that of similar crucible silicon carbide, and its service life is increased by more than 20%. Effectively reduce the frequency of replacement, reduce customer operating costs.

4 For electromagnetic induction furnace

The traditional silica carbide crucible is usually not magnetic conductive on the electromagnetic induction furnace, and our specially developed new material silicon carbide crucibles has its own heating performance, significantly improving the heating efficiency. The service life of electromagnetic induction furnace can reach more than a few years, far exceeding the industry average level.

Product features

High temperature resistance: Our silica carbide crucibles withstand the high temperature of 1600°C to 1800°C, suitable for a variety of industrial scenarios.

Thermal shock resistance: Our silica carbide crucible is not easy to crack under rapid temperature changes to ensure stable operation.

High thermal conductivity: high heat conduction efficiency, significant energy saving effect.

High strength: Our silica carbide crucible is strong structure, wear resistance, suitable for high-strength industrial environment.

Material: High purity silicon carbide (SiC) and graphite silicon carbide composite material.

Size: Customizable, available in a variety of capacities and shapes.

Surface treatment: Special coating or smooth treatment is available on request.Customer value

Lower costs: Our silicon carbide graphite crucibles have longer service life and higher thermal conductivity, significantly reducing customer operating costs.

Improve efficiency: Our silicon carbide graphite crucibles have efficient thermal conductivity and self-heating performance, shorten heating time, improve production efficiency.

Environmental protection and energy saving: Our silicon carbide graphite crucibles have energy-saving design, reduce energy consumption, in line with environmental requirements.

Quality assurance: Our silicon carbide graphite crucibles have no gas design, to ensure the purity of liquid aluminum, improve product quality.

FAQS

Q1: What are the advantages of silicon carbide graphite crucibles compared to traditional graphite crucibles?

✅ Higher Temperature Resistance: Can withstand 1800°C long-term and 2200°C short-term (vs. ≤1600°C for graphite).
✅ Longer Lifespan: 5x better thermal shock resistance, 3-5x longer average service life.
✅ Zero Contamination: No carbon penetration, ensuring molten metal purity.

Q2: Which metals can be melted in these crucibles?
▸ Common Metals: Aluminum, copper, zinc, gold, silver, etc.
▸ Reactive Metals: Lithium, sodium, calcium (requires Si₃N₄ coating).
▸ Refractory Metals: Tungsten, molybdenum, titanium (requires vacuum/inert gas).

Q3: Do new crucibles require pre-treatment before use?
Mandatory Baking: Slowly heat to 300°C → hold for 2 hours (removes residual moisture).
First Melt Recommendation: Melt a batch of scrap material first (forms a protective layer).

Q4: How to prevent crucible cracking?

Never charge cold material into a hot crucible (max ΔT < 400°C).

Cooling rate after melting < 200°C/hour.

Use dedicated crucible tongs (avoid mechanical impact).

Q5: How to prevent crucible cracking?

Never charge cold material into a hot crucible (max ΔT < 400°C).

Cooling rate after melting < 200°C/hour.

Use dedicated crucible tongs (avoid mechanical impact).

Q6: What is the minimum order quantity (MOQ)?

Standard Models: 1 piece (samples available).

Custom Designs: 10 pieces (CAD drawings required).

Q7: What is the lead time?
⏳ In-Stock Items: Ships within 48 hours.
⏳ Custom Orders: 15-25 days for production and 20 days for mould.
